Description
This 4.5″ System for the 2011-2016 Super Duty is one the best riding suspension systems ICON has ever developed. This system has been engineered using the highest quality materials and components. The dual rate front coil springs combined with our ICON 2.5 Aluminum Series CDCV shocks give these trucks the performance they so desperately need. This system comes complete with front coils, shocks, radius arm drop down brackets, rear blocks and U-bolts and our patented adjustable track bar giving the front end of these trucks perfect track alignment. The Stage 4 system also includes shocks that feature the ICON Compression Damping Control Valve (CDCV) and our radius arm system for the ultimate in shock technology and suspension technology.
This Stage 4 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty Radius Arm System that feature a sealed pivot bushing that minimizes road feedback and ensures a long life and quiet operation. Additionally, their fabricated, fully boxed design ensures strength and utilizes a profile optimized for tire clearance at full steering lock, making a 37″ tall tire clear without coming in contact with the radius arm.
- 50% increase in wheel travel
- Corrosion resistant anodized aluminum shock bodies with 7/8″ shafts (2.5 Aluminum Series shocks)
- Fabricated radius arms with drop brackets offer on vehicle caster adjustment, increased strength, and improved tire clearance at steering lock
- 100% bolt-on system – no cutting or welding necessary for install
- Less body-roll than stock truck
- 4.5″ more travel from ride height to front bump stops
- Dual rate coil spring
- Lifetime guarantee that coil springs won’t sag
- Clears 35″ tall tires & 37″ tall tires w/ minor trimming
- No change in towing capacity
- No drive shaft modifications needed
Kit Components
- 64050 QTY:1 08-22 FSD FRONT 4.5″ BOX KIT
- 64010 QTY:1 05-19 FSD FRONT 4.5″ DUAL RATE SPRING KIT
- 64035 QTY:1 05-16 FSD ADJ TRACK BAR W/FK ROD END
- 64041 QTY:1 05-22 FSD RADIUS ARM SYSTEM
- 64045 QTY:1 11-16 FSD RADIUS ARM DROP KIT
- 195275 QTY:1 99-25 FSD 5″ BLOCK KIT
- 67002 QTY:1 11-25 FSD REAR 17″ U-BOLT KIT
- 67710CP QTY:1 05-22 FSD 4WD 4.5″ FRONT 2.5 VS PB CDCV PAIR
- 37701CP QTY:1 99-25 FSD 3-6″ REAR 2.5 VS PB CDCV PAIR
Additional fitment info from vendor. (Please verify and see fitment disclaimer below)
- 2016 Ford F-250 Super Duty DIESEL 4WD
- 2016 Ford F-350 Super Duty DIESEL 4WD
- 2015 Ford F-250 Super Duty DIESEL 4WD
- 2015 Ford F-350 Super Duty DIESEL 4WD
- 2014 Ford F-250 Super Duty DIESEL 4WD
- 2014 Ford F-350 Super Duty DIESEL 4WD
- 2013 Ford F-250 Super Duty DIESEL 4WD
- 2013 Ford F-350 Super Duty DIESEL 4WD
- 2012 Ford F-250 Super Duty DIESEL 4WD
- 2012 Ford F-350 Super Duty DIESEL 4WD
- 2011 Ford F-250 Super Duty DIESEL 4WD
- 2011 Ford F-350 Super Duty DIESEL 4WD
